Ashdown Electric Guitar Amps
The SX Line
Introducing the Revolutionary SX Range of Valve Amplifiers by Ashdown: A Perfect Blend of Classic Elegance and Modern Innovation !
Ashdown, renowned for its excellence in bass guitar amplification, is proud to present the SX range of Valve Amplifiers, a true masterpiece of sonic engineering. These classic-style valve amps pay homage to the vintage legends while infusing a host of innovative features that make it an exceptional, modern, and cost-effective gem for musicians and audio aficionados alike.
Unleash the Power of Valves
Powered by 3 x ECC83 and 2 x EL34 valves, the SX-40 delivers a stunning 40 watts (RMS) of pure valve-driven power into 8 and 16 ohms, allowing you to experience that rich, warm, and dynamic tone you've been yearning for. Whether you're in the studio, on stage, or jamming in your garage, this amplifier guarantees that your sound remains authentically classic.
A Channel for Every Mood
The SX range features a dedicated clean channel with independent bass and treble controls, offering pristine, crystal-clear tones for your rhythm work. But that's just the beginning. The drive channel is split into channels 2 and 3, each equipped with its own gain control. This allows you to effortlessly transition from sweet, smooth overdrive to roaring distortion with a simple twist of a knob or a tap of your foot on the footswitch.
Total Sonic Control
Customize your sound with precision using the comprehensive EQ controls, including contour, bass, middle, and treble. Fine-tune your reverb settings with the digital Digilog by Belton reverb, providing that lush, immersive ambiance to your music. Master volumes for channels 2 and 3 give you total control over the overall output level.
Versatile Connectivity
The SX line is equipped with an array of connectivity options to adapt to your needs. The back panel boasts speaker jacks for 8 and 16-ohm connections, ensuring compatibility with your preferred cabinets. The buffered effects loop with 'in' and 'out' jacks features a convenient level control, allowing you to integrate your pedalboard seamlessly.
Studio-Quality Recording
For recording enthusiasts, the SX-40 offers two recording out jacks: 'live' keeps your speakers active, while 'dead' mutes for silent recording. This flexibility ensures your recordings are studio-quality, capturing every nuance of your performance.
Customizable Volume Control
One of the standout features of the SX range is the rear panel switch that lets you toggle between 'stage' and 'studio' settings. This ensures that you can adjust the volume without sacrificing the authentic valve amp drive at lower settings, sparing your neighbours from any unwelcome noise disturbances.
The SX range of Valve Amplifiers by Ashdown is the ultimate combination of classic and modern, offering incredible tonal possibilities, impeccable craftsmanship, and a wealth of features to meet the demands of today's musicians. Whether you're on stage, in the studio, or practicing at home, the SX delivers unparalleled sonic excellence. It's time to embrace the timeless beauty of valve amplification with a touch of modern innovation. Discover the SX range and let your music come alive in ways you've never imagined.
The Ashdown SX range of amplifiers bring tone and flexibility to today’s hard working guitarist. Driven by 3 x ECC83 tubes in the preamp, the amplifiers feature 3 channels offering huge flexibility whether at home, rehearsal or in the studio.
The 20 Watt head and combo employ 2 x EL84 tubes in the power section while the 40 Watt combo uses the classic combination of 2 x EL34s. The dedicated clean channel has an independent EQ (Bass & Treble) and offers lush crystal clean tones through to a warm, bluesy crunch when driven hard. Channels 2 and 3 have a shared EQ that features Bass, Middle and Treble, along with a Contour control for quick and easy fine tuning of your sound. Channels 2 and 3 both have independent Volume and Gain controls meaning you can switch from a rhythm to boosted lead tone simply at the click of a switch.
Whether it’s huge British crunch or all the way to American-styled, fully saturated tones, the SX heads and combos will not disappoint. Channels can be changed via the push buttons on the front panel or by using an FS-2 footswitch. The SX amplifiers also feature digital reverb, an FX loop with level control and 2 recording out sockets that simulate the tone taken from a mic in front of a 4x12 cabinet – one leaving the amplifier operational and one which mutes the amplifier ’s power amp section for silent recording. The heads also feature 2 x 8Ω speaker outputs and 1 x 16Ω output to allow connection to a wide variety of cabinets.
Opting for Celestion speakers in our NEW range of cabinets and combos ensures the core tone of these amplifiers are represented in the correct way. Delivering glorious all valve tones night after night on stage or in the studio.
SPECIFICATIONS
ASHDOWN SX-5C
Discover the pinnacle of sonic engineering with the Ashdown SX 5 COMBO—a 5-watt, all-tube guitar combo that seamlessly blends classic and modern tones. Crafted with precision, this amplifier features a 1x12” Celestion-loaded speaker, 1xECC83, 1xEL84 tubes, digital reverb, effects loop, and a speaker-emulated recording out. The SX range by Ashdown is designed for today's discerning musicians, offering unparalleled tonal possibilities and impeccable craftsmanship. Whether you're performing live, recording in the studio, or honing your skills at home, the SX ensures your sound remains authentically classic with a touch of modern innovation.
SPECIFICATIONS:
Weight: 14.1kgs / 31lbs
Dimensions: H: W: D: mm/inches 470 x 440 x 240 - 18.5 x 17.3 x 9.4
Single channel Pre amplifier with Genuine Accutronics reverb block
1 x JJ Electronics ECC83s preamplifier tube
Bass, middle, treble and controls
Master volume control
Stealth switch reduces overall volume and activates Speaker Tone compensation for studio use
Series effects loop
Aux input for backing tracks, MP3 etc.
Speaker mute switch for silent recording (activates headphone output)
Recording out socket- filtered to simulate the response of a Celestion Alnico speaker
Up to 5 Watts output from 1 x JJ Electronics EL84 valve
16 & 8 Ohm speaker outputs for use with a different speaker cabinets
Plywood Tolex covered classically styled cabinet. Combo is fitted with a Celestion 12” speaker.
ASHDOWN SX-5H
Discover a new realm of sonic possibilities with the Ashdown SX 5 Head, a 5-watt all-valve guitar amplifier that seamlessly marries classic warmth with modern innovation. Unleash the power of 1xECC83 and 1xEL84 tubes, delivering 5 watts of pure, dynamic tube power. Immerse yourself in an authentic sound experience, whether you're in the studio, on stage, or honing your skills at home.
The SX range of Valve Amplifiers by Ashdown represents the pinnacle of sonic engineering, ensuring impeccable craftsmanship and an array of features to cater to the demands of today's discerning musicians. From the digital reverb that adds a touch of spaciousness to your sound to the effects loop for seamless integration of your pedalboard, the SX 5 Head is designed for versatility.
Embrace the timeless beauty of valve amplification with the SX range, where classic meets modern. Experience unparalleled sonic excellence as you elevate your music to new heights. Ashdown, the home of tone, invites you to unleash your sound with the Ashdown SX 5 Head—a true companion for the hardworking guitarist seeking tone and flexibility.
SPECIFICATIONS:
Weight: Head - 9.2 Kgs / 20.3Lbs
Dimensions: H: W: D: mm/inches 220 x 435 x 240 - 8.6 x 17 x 9.4
Single channel Pre amplifier with Genuine Accutronics reverb block
1 x JJ Electronics ECC83s preamplifier tube
Bass, middle, treble and controls
Master volume control
Stealth switch reduces overall volume and activates Speaker Tone compensation for studio use
Series effects loop
Aux input for backing tracks, MP3 etc.
Speaker mute switch for silent recording (activates headphone output)
Recording out socket- filtered to simulate the response of a Celestion Alnico speaker
Up to 5 Watts output from 1 x JJ Electronics EL84 valve
16 & 8 Ohm speaker outputs for use with a different speaker cabinets
Plywood Tolex covered classically styled cabinet.
ASHDOWN SX-50H
Immerse yourself in the rich, warm, and dynamic tones of the Ashdown SX 50H, a 50-watt all-valve amplifier engineered with precision in the UK. Boasting three ECC83 preamp valves and two EL34 power valves, this amplifier offers a versatile three-channel setup. The clean channel, with its independent EQ and the sonic characteristics of ECC83 tubes, provides a pristine foundation for your tone. The two overdrive channels, driven by EL34 power valves, share a comprehensive EQ, allowing you to sculpt your sound with precision.
With volume and gain controls for each overdrive channel, you have the flexibility to explore a spectrum of musical genres. Beyond its exceptional tonal capabilities, the Ashdown SX 50H integrates digital reverb, an effects loop with level control, and a speaker-emulated recording out, making it a comprehensive solution for studio sessions or live performances. Elevate your sound experience in any setting, as the SX range combines classic valve warmth with modern innovation.
SPECIFICATIONS:
Weight: Head - 13.5 Kgs / 29Lbs
Dimensions: H: W: D: mm/inches 230 x 570 x 245 - 9 x 18.5 x 9.4
50 Watt all-tube power
3xECC83, 2xEL34 tubes
Three footswitchable channels
Clean channel with independent EQ
2 x overdrive channels with shared EQ
Volume and Gain control for each overdrive channel
Digital reverb, effects loop with level control
Speaker-emulated recording out
1 X 12” CABINETS
ASHDOWN SX 112A
ASHDOWN SX-112F
Introducing the Ashdown SX 112 series, a compact yet powerful solution for any stage setting. Choose between the SX 112 Flat with its flat baffle or the SX 112 A featuring an angled baffle, catering to different preferences in sound projection. Designed to seamlessly complement our SX 5 Head, these cabinets boast premium ply construction and a closed-back design for optimal performance.
What sets these cabinets apart is the Celestion 70/80 speakers, carefully selected for their detailed and crisply defined sound. With a tightly controlled low-end and punchy upper mid-range, these speakers add a distinctive character to your amp. Whether used individually, in pairs, or quartets, the SX 112 series delivers a wide range of sounds and styles while maintaining the unmistakable Celestion signature.
SPECIFICATIONS:
SX-112F- SX 1x12” FLAT Closed Back Ply Cabinet Celestion speaker
Weight: 12.7Kgs / 27Lbs
Dimensions: H: W: D: mm/inches
SX-112A - SX 1x12” Angled Closed Back Ply Cabinet Celestion speaker
Weight: Kgs / Lbs
Dimensions: H: W: D: mm/inches
Celestion 70/80 speakers
Ply construction, closed-back design
Tailored design to complement SX heads
2 X 12” CABINETS
ASHDOWN SX 212A
ASHDOWN SX 212F
Introducing the Ashdown SX 212 cabinets – a compact powerhouse for the stage. Whether you prefer the flat baffle of the SX 212 Flat or the angled baffle of the SX 212 A, both options house 2 x 12” offset speakers. These cabinets are the perfect companions for our SX Heads, featuring premium ply construction and Celestion-loaded enclosures meticulously designed to complement the NEW SX heads. The Celestion 70/80 speakers were chosen for their detailed and crisp definition, controlled low-end, and punchy upper mid-range, ensuring a wide range of sounds and styles. Whether used individually, in pairs, or quartets, the SX 212 cabinets add the unmistakable Celestion character to any amp setup.
SPECIFICATIONS:
SX-212F - SX 2x12” FLAT Closed Back Ply Cabinet Celestion speaker
Weight: 12.7Kgs / 27Lbs
Dimensions: H: W: D: mm/inches
SX-212A - SX 2x12” Angled Closed Back Ply Cabinet Celestion speaker
Weight: Kgs / Lbs
Dimensions: H: W: D: mm/inches
Celestion 70/80 speakers
Ply construction, closed-back design
Tailored design to complement SX heads
4 X 12” CABINET
The Ashdown SX 412 cabinet is the ideal choice for musicians seeking a compact yet powerful 4 x 12" speaker solution. Perfectly paired with our SX Heads, this cabinet boasts premium ply construction and Celestion 70/80 speakers. The closed-back design and tailored construction ensure a seamless integration with the SX heads, providing a detailed, punchy sound with tightly controlled low-end and aggressive upper mid-range. Whether used singly, in pairs, or quartets, the SX 412 delivers the unmistakable Celestion character, making it a versatile choice for a wide range of musical styles.
SPECIFICATIONS:
SX 4x12” Closed Back Ply Cabinet Celestion speaker
Weight: Kgs / Lbs
Dimensions: H: W: D: mm/inches
Celestion 70/80 speakers
Ply construction, closed-back design
Tailored design to complement SX heads
thE kt LINE
The Ashdown Killer Tone Line redefines practice amps with a powerful blend of affordability and performance. Crafted with precision, these transistor-based amplifiers are engineered to deliver exceptional tone consistently. They capture the warmth of a tube amp while offering modern features tailored to the needs of aspiring guitarists.
These amps cater to your practice preferences with a headphone output for silent sessions and a line input for jamming along with your favourite tracks. The real magic unfolds with the KT-15FX and KT-30FX models, which come equipped with a versatile 16-way digital effects unit, adding a new dimension to your practice sessions.
Simplicity meets effectiveness in a design that’s not only functional but also budget-friendly, making it accessible to guitarists of all levels. With three options in the lineup, you’re sure to find the perfect amp to suit your needs.
KT-15
Introducing the KT-15, the latest addition to the All NEW Killer Tone practice amp lineup. This 15-watt powerhouse is meticulously designed to deliver Killer Tone consistently. With tube-like warmth and modern features, it's tailored for aspiring guitarists. The KT-15 includes a line input for jamming and a headphone out for silent practice – your perfect musical companion.
15 Watts
2 Channels
Headphone Out
8” Speaker
Line Input
KT-15FX
Meet the KT-15 FX, the latest addition to the All NEW Killer Tone practice amp series. This 15-watt powerhouse is meticulously designed to deliver Killer Tone day in and day out. Tuned to replicate the warmth of a tube amp, it's packed with modern features tailored for aspiring guitarists. With a 16-way digital effects unit, line input for jamming, and headphone out for silent practice, the KT-15 FX is your all-in-one solution for killer sound.
15 Watts
16 Way Digital Effects Unit
2 Channels
Headphone Out
8” Speaker
Line Input
KT-30FX
Introducing the KT-30 FX, the latest gem in the All NEW Killer Tone practice amp series. This 30-watt powerhouse is meticulously designed to deliver Killer Tone every day. Tuned to emulate the warmth of a tube amp, it's enriched with modern features tailored for aspiring guitarists. With a 16-way digital effects unit, line input for jamming, and headphone out for silent practice, the KT-30 FX is your ultimate companion for killer sound
30 Watts
16 Way Digital Effects Unit
2 Channels
Headphone Out
10” Speaker
Line Input
Peacemaker 2
Peacemaker 2 Combo
Immerse yourself in the rich, dynamic sound of the Ashdown Peacemaker 2 Combo, a testament to British craftsmanship and engineering excellence. Designed and crafted in the UK, this combo amplifier offers a comprehensive suite of features tailored to meet the needs of today’s discerning guitarists.
At its core, the Peacemaker 2 Combo features a single-channel preamplifier with two voiced inputs and Dark & Light Voicing options, providing musicians the flexibility to explore a diverse range of tones, from vintage American cleans to classic British crunch. The inclusion of premium JJ Electronics ECC83 preamplifier tubes ensures exceptional sonic performance, with warmth, clarity, and dynamic range that will inspire your playing.
Equipped with a 12” UK-built Celestion Creamback speaker, the Peacemaker 2 Combo delivers legendary British tone with unparalleled clarity, definition, and punch. Whether you’re in the studio, on stage, or practicing at home, this amplifier provides ample power and headroom, with up to 2 watts output from the JJ Electronics 6v6 valve.
House in a stylish birch plywood cabinet wrapped in classic Tolex covering, the Peacemaker 2 Combo exudes timeless style and durability. With its compact dimensions of H: 440mm W: 400mm D: 280mm and manageable weight of 13kg, this amplifier is equally at home in the studio or on the road. Experience the ultimate in amplifier performance with the Ashdown Peacemaker 2 Combo, where tradition meets innovation for uncompromising tone and versatility.
Peacemaker 2 Head
Step into a world of sonic excellence with the Ashdown Peacemaker 2 Head, meticulously crafted in the UK to deliver unparalleled tone and performance. Representing the pinnacle of amplifier innovation, this amplifier combines classic design elements with modern features to meet the demands of today’s discerning musicians.
At its core, the Peacemaker 2 Head features a single-channel preamplifier with two voiced inputs, offering a versatile platform for exploring a wide range of musical styles. With the Dark & Light Voicing options, guitarists can effortlessly dial in the iconic tones of both US and UK amplifiers, from shimmering cleans to searing overdrive.
Driving the Peacemaker 2 Head’s rich, dynamic sound is a pair of JJ Electronics ECC83 preamplifier tubes, renowned for their warmth, clarity, and responsiveness. With intuitive bass, middle, treble, gain, and volume controls, guitarists have complete command over their tone, allowing for endless sonic exploration and experimentation.
Designed for versatility and convenience, the Peacemaker 2 Head features a headphone output with load for silent practice, perfect for late-night sessions or private rehearsals. With up to 2 watts output from the JJ Electronics 6v6 valves and 8-16 Ohm outputs, this amplifier delivers ample power and headroom for any performance scenario.
Housed in a robust birch plywood cabinet wrapped in classic Tolex covering, the Peacemaker 2 Head exudes timeless style and durability. Compact and lightweight, with dimensions of H: 220mm W: 405mm D: 190mm and weighing just 7.5kg, this amplifier is equally at home in the studio, on stage, or on the road. Experience the ultimate in amplifier craftsmanship with the Ashdown Peacemaker 2 Head, where tradition meets innovation for uncompromising tone and performance.
